Key Features
- Class 0.2S Active / 0.5S Reactive
- Three Phase (3P3W / 3P4W)
- Voltage Wide Range
- CT/VT
- Power Quality Class S (IEC 61000-4-30)
- Substation ready with IEC 61850
- High data memory for network monitoring
- Secure and utility-grade design
Electrical Specifications
Voltage 57 – 240V (L-N) / 100 – 415V (L-L)
Current CT Range: 1/10A
Measurements & Accuracy
- Active, Reactive & Apparent Energy
- Import / Export / Absolute energy
- Per phase & total measurements
- True RMS voltage & current
- Power factor, frequency & phase angle
- Transformer & line loss compensation
Power Quality Monitoring
- Voltage sag & swell / Voltage interruption / Voltage unbalance
- Voltage harmonics & THD
- Power frequency monitoring
- IEC 61000-4-30 Class S
Load Profile & TOU
- Multi-channel load profile / Programmable intervals / Up to 8 TOU rates
- Daily, weekly & seasonal calendars
- Maximum demand (block or rolling)
Communication & Integration
- Optical port (IEC 62056-21) / Ethernet / RS-485 (2 or 4 wire)
- DLMS / Modbus RTU & TCP
- IEC 61850 substation protocol
- LTE/GSM WIRELESS COMMUNICATION
Security & Reliability
- Secure boot / AES-128 encryption / Multi-level user access
- Tamper detection & alarms / Event and alarm logging
Applications (Use Cases)
- Transmission & Distribution networks
- Substation monitoring
- Power quality analysis
- Grid edge metering
- Utility & industrial metering
Standards & Compliance
- IEC 62052 / IEC 62053 / IEC 61000-4-30 / MID / IEC 61850 / DLMS
