Key Features
- Class 0.5S Accuracy Reliable high-precision metering for utility and HV applications.
- HVCT Ready Design Optimized for current transformer-based installations.
- Smart Grid Compatible DLMS & IDIS compliant for modern AMI systems.
- Advanced Power Quality Voltage sag/swell, THD and harmonic monitoring.
- Three Phase (3P3W / 3P4W)
- Import / Export Energy Measurement
- Load Profile & TOU Tariffs
- Anti-Tamper & Event Logging
- Modular Communication Options
- High Data Security (AES-128)
Electrical Specifications
- Voltage: 40-110 V
- Current CT Range: 1/6A & 1/10A
Measurements
- Active, Reactive & Apparent Energy
- Per quadrant energy measurement
- Maximum Demand & Power Factor
Flexible Communication & Integration
- Optical Port (IEC 62056-21)
- DLMS / IDIS / Modbus RTU
- Optional RF Communication Module
- Remote configuration & firmware upgrade
- Compatible with EDMI HES & AMI platforms
Security & Anti-Tamper
- Magnetic tamper detection
- Reverse current detection
- Lid & terminal cover opening alarms
- Encrypted communication (AES-GCM-128)
- Event & alarm logging
Applications (Use Cases)
- Utility Billing
- Transmission & Distribution
- HV / MV Substations
- Smart Grid & AMI Projects
Standards & Compliance
IEC | DLMS | IDIS | WELMEC | EN 50470
